|MPO/MTP||SM standard||SM low loss||MM standard||MM low loss|
|Return loss||APC≧50dB |
|Repeatability||≦0.30dB(plugging over 500 times)||≦0.30dB(plugging over 1000 times)|
|Interchangeability||≦0.30dB( matching with any connector)|
|Extension||≦0.30dB (maximum tension 66N)|
|Temperature range||-40℃ ~ +75℃|
1. The MPO fiber optic cable connector is in full compliance with IEC 61754-7 and GR-1435-Core standards and regulations.
2. Due to the extensibility and modularity of the product design, it is easy to move, add, and change components.
3. The fiber cable connector uses single MTP/MPO joint with 8/12/24 core to assemble into the 1U rack, among which containing 96 LC jumper joints, so as to save layout space, shorten the down time and speed up installation.
4. A complete variety of optical fiber and cables are available to ensure custom requirements
5. The push and pull interlocks and the two dowel pins on the sliding sleeve can accurately locate the MPO joint with more than 1,000 insertion cycles.
6. The preferred scheme and data center of high speed communication systems
7. Used for parallel optical applications: Infiniband, the data rate up to 120GB/s; multimode OM3, OM4, and OS2 optical fibers for the coming 40GB/s and 100GB/s Ethernet protocols
Xinhaixun offers customers a variety of fiber optic passive components, a specialized MPO fiber optic cable connector manufacturer and supplier, we are offering a wide range of fiber beam splitters, optical patch cable, optical adapter, optical coupler, WDM. Use quality manufacturing and testing equipment, we provide quality optical fiber connector component for fiber optic communication and networking applications.
